HKS MAX-IV SP FULL KIT FOR 1993-1998 TOYOTA SUPRA JZA80 (hks80250-AT002)

The coil-over suspension gives awesome control and a comfortable ride on the street during sporty driving. These are perfect for daily street driving with sporty style and performance handling. It provides a well-balanced comfortable ride even with its low-down suspension stance. Customized spring rates are also available upon request at checkout.

APPLICATION

• TOYOTA SUPRA (1993, 1994, 1995, 1996, 1997, 1998)

FEATURES

• Designed Application: Street Sport Model
  General Specification:
  -Damping Force Adjustment:
  -- Front: 30 Steps
  -- Rear: 30 Steps
• Upper Mount:
  - Front: Pillow Ball
  - Rear: Pillow Ball
• Spring Rate Change at the factory:
  - Front: Possible
  - Rear: Possible
• Helper Spring (Spring Rate N/mm):
  - Front: Yes (19.8N/mm)
  - Rear: Yes (19.8N/mm
• Drivable Range High - Low (mm):
  - Front: 691~571
  - Rear: 668~570
  - Note: Drivable range that there is no contact of car body or arms etc. (However, change of tire/wheel size may cause a problem.)

• - Springs Specification -
  Spring Rate N/mm (kgf/mm):
  - Front: 216(22) (OPTION : +/-20(2))
  - Rear: 157(16) (OPTION : +/-20(2))
• Free Height (mm):
  - Front: 170
  - Rear: 200
• - Damper Specification -
  Damper Force (Rebound/Damping):
  - Front: 1600/450
  - Rear: 800/400
  - Note: Damping force is at piston speed 0.1m/sec.
• The default position of Dial:
  - Front: 15
  - Rear: 15
• Remaining Damper Stroke (Rebound/Damping) (mm):
  - Front: 37/62
  - Rear: 59/77
