ACT 95-04 Toyota Tacoma XT/Race Sprung 4 Pad Clutch Kit (actTA1-XTG4)

ACT's TA1-XTG4 kit features a powerful Xtreme pressure plate and spring center 4 pad race disc delivering ultra-high torque capacity, aggressive engagement, quiet operation, and increased toughness to withstand the demands of off-road racing. ACT’s exclusive diaphragm design dramatically increases clamp load, reduces deflection, and maximizes clutch life. All diaphragms endure a four-stage heat-treating process for unparalleled performance. ACT precision pressure plate cover stampings provide rigidity and consistency while precision-machined pressure plate castings absorb heat. ACT’s spring-center 4 pad race discs boast quality parts throughout, with robust spring-center sections to absorb driveline shock and premium ceramic friction materials to hold power even under the most abusive conditions.

NOTE

• SPECIAL ORDER

APPLICATIONS

• Toyota Tacoma (1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004)

FEATURES

• Feel: Moderate to heavy pedal effort, aggressive engagement, OE to mild gear rattle, confidence during hard shifts.
• Life: Moderate friction life, extended by ACT's exclusive diaphragm design, increased durability and heat capacity.
• Quality: Carefully engineered, precisely assembled, accurately balanced, uses premium ceramic friction materials for high heat tolerance and maximum performance, premium bearings and hardware.
• Recommended Use: Recommended for high torque race use.
• ACT Difference: 100% clamp load tested and dynamically computer balanced for smooth high RPM reliability, key areas induction hardened for longer life.

SPECIFICATIONS

• Item Description: XT-O/Race Sprung 4 Pad
• Product Weight (lbs.): 16.8
• Torque Capacity (ft/lbs.): 450
• Torque Capacity Over OE: 107%
• Disc Material: Ceramic
• Clutch Disc Diameter (Inches): 9.3
• Clutch Disc Diameter (Millimeters): 236
• Input Shaft Diameter (inches): 1.125
• Pressure Plate Type: Xtreme
• Warranty: 12 Months
